28G SFP28 AOC

GIGALIGHT's 28G SFP28 AOC (Active Optical Cable) assemblies are designed to support 8G/16G/32G Fibre Channel, suitable for SAN (Storage Area Network) links up to 100m or 300m over multi-mode fiber.Get a Quote

Features

Applications

Datasheets

Hot-pluggable SFP28 form factor full-duplex active optical cable assembly
850nm VCSEL laser and PIN photo-detector
Data rate up to 28.05Gbps
Compliant with SFP28 MSA (SFF-8402), SFF-8472 and 32G Fibre Channel
Compliant with 8G/16G Fibre Channel
Internal CDR on both transmitter and receiver channels
MMF cable with customizable length up to 100m or 300m
1W maximum power dissipation per 32GFC SFP28 SW module
Case operating case temperature range: C-Temp or I-Temp
3.3V power supply voltage
Built-in digital diagnostic functionality
RoHS compliant (lead free)

Part Number	Product Description
GSS-MDO280-xxxC	28G SFP28 AOC, 28G SFP28 to 28G SFP28, 32GFC, 850nm, 1m-100m, C-Temp
GSS-MDO280-xxxT	28G SFP28 AOC, 28G SFP28 to 28G SFP28, 32GFC, 850nm, 1m-100m, I-Temp
GSS-MDO280-exxxC	28G SFP28 AOC, 28G SFP28 to 28G SFP28, 32GFC, 850nm, 1m-300m, C-Temp
GSS-MDO280-exxxT	28G SFP28 AOC, 28G SFP28 to 28G SFP28, 32GFC, 850nm, 1m-300m, I-Temp

Note：The "xxx" in the part number means the cable length, e.g., 001=1m, 002=2m, 010=10m, 100=100m, etc.

8G/16G/32G Fibre Channel
Storage Area Network

32GFC SFP28 AOC - GSS-MDO280-xxxC

32GFC SFP28 Enhanced AOC - GSS-MDO280-ExxxC
