50G SFP56 BiDi 10km/30km Transceivers (I-Temp Optional)

GIGALIGHT's 50G eCPRI SFP56 BiDi optical transceiver modules are designed for 5G fronthaul and support 50GE/eCPRI links reach up to 10km or 30km over single SMF.Get a Quote

Features

Applications

Datasheets

More

Hot-pluggable SFP56 form factor full-duplex transceiver module
50G PAM4 1270nm/1330nm EML and PIN or APD
Data rate up to 53.125Gbps (26.5625GBd PAM4)
Compliant with SFP56 MSA (SFF-8402) and eCPRI specification
Compliant with IEEE 802.3cp 50GBASE-BR10/50GBASE-BR20
Reach up to 10km or 30km over SMF with FEC
Simplex LC receptacle
3W maximum power dissipation
Case operating temperature range: I-Temp
Single 3.3V power supply
Built-in digital diagnostic functionality
RoHS compliant (lead free)

Part Number	Product Description
GBS-2733500-LRT	I-Temp 50G SFP56 BiDi Tx-1270nm Rx-1330nm 10km Transceiver
GBS-3327500-LRT	I-Temp 50G SFP56 BiDi Tx-1330nm Rx-1270nm 10km Transceiver
GBS-2733500-L3T	I-Temp 50G SFP56 BiDi Tx-1270nm Rx-1330nm 30km Transceiver
GBS-3327500-L3T	I-Temp 50G SFP56 BiDi Tx-1330nm Rx-1270nm 30km Transceiver

IEEE 802.3cp 50GBASE-BR10
IEEE 802.3cp 50GBASE-BR20
5G Fronthaul eCPRI

I-Temp 50G SFP56 BR30-D Transceiver - GBS-3127500-L3T

　　　　　　　　　　　　　　　　　　　　

I-Temp 50G SFP56 BR30-U Transceiver - GBS-2731500-L3T

　　　　　　　　　　　　　　　　　　　　

I-Temp 50G SFP56 BR10-D Transceiver - GBS-3327500-LRT

　　　　　　　　　　　　　　　　　　　　

I-Temp 50G SFP56 BR10-U Transceiver - GBS-2733500-LRT

　　　　　　　　　　　　　　　　　　　　

　　　　　
