4×12G-SDI Video Optical Extenders

GIGALIGHT's 4×12G-SDI video optical extenders are used to extend the reach of 8K video transmission between SDI Source and Sink devices over fiber. The transmission distance can be extended up to 10km with 12G-SDI CWDM optical modules.Get a Quote

Features

Applications

Datasheets

Extends 4 lanes of 12G-SDI signals up to 10km over fiber
Data rate per lane up to 12G, total 48G for 8K
Compliant with SMPTE-424M/292M/295M/297M/305M/310M and DVB-ASI
Plug and Play
Longer and thinner cable without EMI/RFI emissions
Operating case temperature 0 to 60℃
All-metal housing for superior EMI performance
RoHS compliant (lead free)

Part Number	Product Description
G-SDI-E-4*12G-T	4×12G-SDI Optical Transmitter Extender
G-SDI-E-4*12G-R	4×12G-SDI Optical Receiver Extender

Live Broadcast
8K Screen
8K Camera
Video Meeting
Security Monitoring

4 x 12G-SDI Optical Fiber Extender - G-SDI-E-4*12G-T/G-SDI-E-4*12G-R
