SFP+ XG-PON&GPON OLT Class C+ 20km Optical Transceiver

GIGALIGHT SFP+ XG-PON&GPON OLT Class C+ 20km optical transceiver module is a combination of XG-PON OLT and GPON OLT optical modules, adopts SFP+ package, and complies with ITU-T G.987.2 and G.984.2 standards. The module can support XG-PON and GPON transmission on a single fiber. The XG-PON function supports 9.953Gbps continuous mode transmission of 1577nm EML laser and 2.488Gbps burst mode reception of 1270nm APD/TIA. The GPON function supports 2.488Gbps continuous mode transmission of 1490nm DML laser and 1.244Gbps burst mode reception of 1310nm APD/TIA.


  • Hot-pluggable SFP+ package
  • Compliant with SFP+ MSA and ITU-T G.987.2/G.9807.1 standards
  • Support XGS-PON OLT Class N2-E application
  • 9.953Gbps 1577nm EML Continuous Mode Transmitter
  • 9.953Gbps/2.488Gbps 1270nm APD/TIA burst mode reception
  • Transmission up to 20km via single-mode fiber
  • Single SC optical interface
  • Typical power consumption 2W
  • Operating Temperature: Commercial Grade
  • Power supply voltage 3.3V
  • Two-wire interface for integrated digital diagnostic monitoring
  • RoHS 2 Compliant (Lead Free)

Additional information

Product Type

Data Rate

Form Factor





Media Type


, , ,
