50G SFP56 AOC

The GIGALIGHT 50G SFP56 AOC active optical cables are designed for 50G Ethernet links reach up to 70m (OM3) or 100m (OM4) over Multi-Mode Fiber (MMF).Get a Quote

Features

Applications

Datasheets

Part Number	Product Description
GSS-MDO560-001C	50G SFP56 Active Optical Cable, 1m
GSS-MDO560-002C	50G SFP56 Active Optical Cable, 2m
GSS-MDO560-003C	50G SFP56 Active Optical Cable, 3m
...	...
GSS-MDO560-010C	50G SFP56 Active Optical Cable, 10m
...	...
GSS-MDO560-100C	50G SFP56 Active Optical Cable, 100m

Hot-pluggable SFP56 form-factor connectors
Full-duplex active optical cables
850nm VCSEL array and PIN photo-detector array
Internal CDR circuits on both receiver and transmitter channels
Support CDR bypass
Compliant with SFP56 MSA and IEEE 802.3cd 50GBASE-SR
Data rate up to 53.125Gbps
Power consumption < 2W per end
Length up to 70m (OM3) or 100m (OM4) over MMF
Operating case temperature range from 0°C to 70°C
3.3V power supply voltage
RoHS compliant (lead free)

50GBASE-SR Ethernet

50G SFP56 AOC - GSS-MDO560-xxxC
