    400G QSFP112

    The GIGALIGHT 400G QSFP112 pluggable optical transceiver modules support 400G Ethernet and InfiniBand NDR data rates. This portfolio includes SR4 100m, DR4 500m, DR4+/XDR4/FR4 2km, CWDM4 6km, and PLR4 10km etc.

    Get a Quote

    Description

    • Hot-pluggable QSFP112 transceiver modules
    • 4x 100G PAM4 electrical interface
    • 4x 100G PAM4 optical interface
    • Data rate up to 106.25Gbps per channel
    • Compliant with QSFP112 MSA, CMIS and IEEE 802.3
    • Low power dissipation
    • Commercial case operating temperature range
    • Single 3.3V power supply
    • Built-in digital diagnostic functionality
    • RoHS compliant (lead free)

    Ordering Information

    DescriptionCategory Modulation WavelengthDistanceConnectorMax. Power DissipationP/N
    400G QSFP112 VR4III-V4x100G850nm30m(OM3)/50m (OM4)MPO128WGQS-MPO401-VR4C
    400G QSFP112 SR4III-V4x100G850nm70m(OM3)/100m (OM4)MPO128WGQS-MPO401-SR4C
    400G QSFP112 DR4SiPh 4x100G 1310nm500mMPO1210WGQS-SI401DR4C
    400G QSFP112 DR4+SiPh4x100G1310nm2kmMPO1210WGQS-SI401XDR4C
    400G QSFP112 DR4++SiPh4x100G1310nm10kmMPO1210.5WGQS-SI401LDR4C
    400G QSFP112 FR4*III-V/SiPh4x100GCWDM42kmDual LC11WGQS-SPO401-FR4C
    GQS-SI401-FR4C
    400G QSFP112 CWDM4*III-V/SiPh4x100GCWDM46kmDual LC11WGQS-SPO401-CFR4X
    GQS-SI401-CFR4C
    400G QSFP112 LR4*III-V/SiPh4x100GCWDM410kmDual LC11WGQS-SPO401-LR4C
    GOS-SI401-LR4C
    400G QSFP112 LR4III-V4x100GCWDM410kmDual LC10WGQS-SPO401-LR4X
