Immersible 400G

GIGALIGHT’s QSFP112/OSFP-RHS liquid cooling optical module is designed for use in submerged data center 400GBASE-SR4 Ethernet links. It adopts 100G PAM4 and VCSEL technologies and, with the FEC enabled in the system, it can achieve 400Gbps data interconnection within 100 meters over 4 pairs of multimode fibers.

Description

Utilizes hot-pluggable QSFP112/OSFP-RHS form factor
4-channel full-duplex transceiver module
Speeds up to 425Gbps
Compliant with QSFP112 MSA/OSFP MSA and 400GBASE-SR4 Ethernet standards
Supports transmission distances of up to 100m over multi-mode optical fiber with FEC enabled
MPO pigtail
Commercial operating temperature range from 0°C to 60°C
Power supply voltage: 3.3V
Compliant with RoHS environmental standards (lead-free)

Additional information

Product Type	Immersion Liquid Cooling Optics
Data Rate	400G
Application	Data Center
Form Factor	OSFP, QSFP-DD
Media Type	MMF
Protocol	Ethernet
Reach	< 500m
Wavelength	850nm
Interface	MPO/MTP Pigtail

Ordering Information

400G OSFP-RHS SR4	425G	850nm	60m(OM3) 100m(OM4)	MPO12 Pigtail	8	GL-H401SR4-MXXA
400G QSFP112 SR4	425G	850nm	60m(OM3) 100m(OM4)	MPO12 Pigtail	8	GL-Q401SR4-MXXA
