Description

• 4 channels full-duplex transceiver modules per end
• Data rate up to 106.25G per channel
• 4 channels 850nm VCSEL array
• 4 channels PIN photo detector array
• Internal CDR circuits on both receiver and transmitter channels
• Power consumption <8W/end
• Hot Pluggable OSFP RHS form factor and Compliant with CMIS
• Maximum link length of 60m on OM3 Multimode Fiber (MMF)and 100m on OM4 MMFwithFEC
• Built-in digital diagnostic functions
• Operating case temperature 0°C to +70°C
• 3.3V power supply voltage
• RoHS compliant(lead free)
• Single MPO12 connector receptacle
