Immersion Liquid Cooling Extenders and DAC

The GIGALIGHT immersion liquid cooling extenders and direct attach cables (DAC) support immersion liquid cooling applications to deploy common optical transceivers and active optical cables, which can help customers to save the huge cost of immersion liquid cooling optics.

Description

Hot-pluggable copper cable extenders with SFP, QSFP, or QSFP-DD cage
Support 10G-200G pluggable optical transceivers and active optical cables
Nearly zero power dissipation
Case operating temperature range: 0°C to 60°C
RoHS compliant (lead free)

Additional information

Data Rate	100G-112G, 200G
Application	Data Center
Form Factor	QSFP28, QSFP56
Product Type	Immersion Liquid Cooling Optics

Immersion Cooling Extender Series

Products	Form Factor	Data Rate	AWG	Distance	Temperature	Datasheets
25G/50G SFP56 Immersion Cooling Extender	SFP56 TO SFP56 Flat cage	25G/50G	30AWG	50cm	0~70℃	TBD
40G QSFP+ Immersion Cooling Extender	QSFP+ to QSFP+Flat Cage	40G	30AWG	50cm	0~70℃	GLQE-PC400-DXX
100G QSFP28 Immersion Cooling Extender	QSFP28 to QSFP28 Flat Cage	100G	30AWG	50cm	0~70℃	GLQE-PC101-DXX
100G SFP112 Immersion Cooling Extender	SFP112 TO SFP112 Flat cage	100G	30AWG	50cm	0~70℃	TBD
200G QSFP56 Immersion Cooling Extender	QSFP56 to QSFP56 Flat Cage	200G	30AWG	50cm	0~70℃	GLQE-PC201-DXX
200G QSFP-DD Immersion Cooling Extender	QSFP-DD to QSFP-DD Flat Cage	200G	30AWG	50cm	0~70℃	GLQD-PC201-DXX
400G QSFP-DD Immersion Cooling Extender	QSFP-DD to QSFP-DD Flat Cage	400G	30AWG	50cm	0~70℃	GLQE-PC401-DXX
400G OSFP-RHS Immersion Cooling Extender	OSFP-RHS to OSFP-RHS Flat cage	400G	30AWG	50cm	0~70℃	TBD
800G QSFP-DD Immersion Cooling Extender	QSFP-DD to QSFP-DD Flat Cage	800G	30AWG	30cm	0~70℃	GLQE-PC801-DXX
800G OSFP Immersion Cooling Extender	OSFP to OSFP-RHS Flat cage	800G	30AWG	30cm	0~70℃	TBD
800G OSFP to QSFP-DD Immersion Cooling Extender	OSFP to QSFP-DD Flat cage	800G	30AWG	30cm	0~70℃	TBD

Immersion Cooling DAC Series

Products	Data Rate	Distance	Datasheets
10G SFP+ Immersion Cooling DAC	10.52Gbps	7m	GLS-PC100-XXC
25G SFP28 Immersion Cooling DAC	25.78125Gbps	5m	GLS-PC250-XXC
40G QSFP+ Immersion Cooling DAC	41.25Gbps	5m	GLQ-PC400-XXC
100G QSFP28 Immersion Cooling DAC	103.12Gbps	5m	GLQ-PC101-XXC
200G QSFP56 Immersion Cooling DAC	212.5Gbps	3m	GLQ-PC201-XXC
200G QSFP-DD Immersion Cooling DAC	206.25Gbps	3m	GLD-PC201-XXC
400G QSFP-DD Immersion Cooling DAC	425Gbps	3m	GLD-PC401-XXC
400G OSFP-RHS Immersion Cooling DAC	425Gbps	3m	GLO-PC401-XXC
400G QSFP112 Immersion Cooling DAC	425Gbps	3m	GLQ-PC401-XXC
800G QSFP-DD Immersion Cooling DAC	850Gbps	2m	GLD-PC801-XXC
800G OSFP Immersion Cooling DAC	850Gbps	2m	GLO-PC801-XXC
