16GFC SFP+ CWDM 10km/40km Optical Transceiver Module (Industrial Grade Optional)

GIGALIGHT 16GFC SFP+ CWDM optical transceiver module is used for long-distance interconnection of data center storage area network, conforms to 16G fiber channel transmission protocol, and is backward compatible with 4G/8G fiber channel transmission protocol. This series of products uses a pair of single-mode optical fiber transmission, the center wavelength is optional for CWDM series 1271-1611nm (interval 20nm), the distance can reach up to 10km or 40km, and the working temperature range of industrial grade is optional.

Description

  • Full-duplex transceiver integrated module in SFP+ hot-pluggable package
  • Single channel CWDM 1271-1611nm DML/EML and PIN/APD
  • Transmission rate up to 14.025Gbps
  • Compliant with SFP+ MSA and 16G Fiber Channel transmission protocol
  • Backward compatible with 4G/8G fiber channel transmission protocol
  • Using a pair of single-mode optical fiber transmission, the distance can reach up to 10km or 40km
  • Power consumption is less than 1.2W (10km version) or 1.8W (40km version)
  • Dual LC optical interface
  • Available in commercial and industrial temperature ranges
  • Power supply voltage 3.3V
  • Comply with RoHS environmental protection standard (lead-free)



P/N Description
GCP-xx14G-01C 16GFC SFP+ CWDM 10km optical transceiver
GCP-xx14G-01T Industrial 16GFC SFP+ CWDM 10km optical transceiver
GCP-xx14G-04C 16GFC SFP+ CWDM 40km optical transceiver
GCP-xx14G-04T Industrial 16GFC SFP+ CWDM 40km optical transceiver

Additional information

Product Type

Application

Data Rate

Form Factor

Protocol

Interface

Reach

,

Media Type

Wavelength

Data Sheet
