Description
2.5G SONET/SDH CSFP BiDi
| Product Model | Product Description |
|---|---|
| GCB-3448-L2CD | 2.5G SONET/SDH CSFP, OC-48/STM-16, 1310nm-Tx 1490nm-Rx, 20km, SMF, Dual LC connectors |
| GCB-4348-L2CD | 2.5G SONET/SDH CSFP, OC-48/STM-16, 1490nm-Tx 1310nm-Rx, 20km, SMF, Dual LC connectors |
| GCB-3548-L2CD | 2.5G SONET/SDH CSFP, OC-48/STM-16, 1310nm-Tx 1550nm-Rx, 20km, SMF, Dual LC connectors |
| GCB-5348-L2CD | 2.5G SONET/SDH CSFP, OC-48/STM-16, 1550nm-Tx 1310nm-Rx, 20km, SMF, Dual LC connectors |
- Hot-pluggable SFP form factor
- Full-duplex transceiver module
- Dual-channel DFB transmitters and PIN receivers
- Compliant with SFP MSA and synchronous optical network (SONET OC-48 / SDH STM-16) standards
- Compatible with 2G fiber channel standards
- Each channel supports a maximum data rate of up to 2.5Gbps
- Transmission distance of up to 20km over a pair of single-mode fibers
- Dual LC connectors
- Built-in digital diagnostic functions
- Commercial operating temperature range from 0 to 70 degrees Celsius
- Power supply voltage of 3.3V
- Compliant with RoHS environmental standards (lead-free)
1G CSFP BiDi
| Part Number | Product Description |
|---|---|
| GCB-3424-L2CD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1310nm-Tx FP 1490nm-Rx PIN, 20km, SMF, Dual LC connectors |
| GCB-4324-L2CD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1490nm-Tx DFB 1310nm-Rx PIN, 20km, SMF, Dual LC connectors |
| GCB-3424-L2TD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1310nm-Tx FP 1490nm-Rx PIN, 20km, SMF, Dual LC connectors, Industrial Grade |
| GCB-4324-L2TD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1490nm-Tx DFB 1310nm-Rx PIN, 20km, SMF, Dual LC connectors, Industrial Grade |
| GCB-3524-L2CD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1310nm-Tx FP 1550nm-Rx PIN, 20km, SMF, Dual LC connectors |
| GCB-5324-L2CD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1550nm-Tx DFB 1310nm-Rx PIN, 20km, SMF, Dual LC connectors |
| GCB-3524-L2TD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1310nm-Tx FP 1550nm-Rx PIN, 20km, SMF, Dual LC connectors, Industrial Grade |
| G
CB-5324-L2TD |
1G CSFP, GE/1GFC/OC-12/STM-8, 1550nm-Tx DFB 1310nm-Rx PIN, 20km, SMF, Dual LC connectors, Industrial Grade |
| GCB-3424-L4CD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1310nm-Tx DFB 1490nm-Rx PIN, 40km, SMF, Dual LC connectors |
| GCB-4324-L4CD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1490nm-Tx DFB 1310nm-Rx PIN, 40km, SMF, Dual LC connectors |
| GCB-3424-L4TD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1310nm-Tx DFB 1490nm-Rx PIN, 40km, SMF, Dual LC connectors, Industrial Grade |
| GCB-4324-L4TD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1490nm-Tx DFB 1310nm-Rx PIN, 40km, SMF, Dual LC connectors, Industrial Grade |
| GCB-3524-L4CD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1310nm-Tx DFB 1550nm-Rx PIN, 40km, SMF, Dual LC connectors |
| GCB-5324-L4CD | 1G CSFP, GE/1GFC/OC-12/STM-8, 1550nm-Tx DFB 1310nm-Rx PIN, 40km, SMF, Dual LC connectors |
- Hot-pluggable SFP form factor
- Full-duplex transceiver module
- Dual-channel FP/DFB transmitters and PIN receivers
- Compliant with SFP MSA and Gigabit Ethernet standards
- Compatible with synchronous optical network (SONET OC-24 / SDH STM-8) standards
- Each channel supports a maximum data rate of 1.25Gbps
- Transmission distance of up to 20km/40km over a pair of single-mode fibers
- Dual LC connectors
- Built-in digital diagnostic functions
- Commercial operating temperature range from 0 to 70 degrees Celsius or industrial operating temperature range from -40 to +85 degrees Celsius
- Power supply voltage of 3.3V
- Compliant with RoHS environmental standards (lead-free)
155M CSFP BiDi
| Part Number | Product Description |
|---|---|
| GCB-3403-L2CD | 155M CSFP, FE/OC-3/STM-1, 1310nm-Tx FP 1490nm-Rx PIN, 20km, SMF, Dual LC connectors |
| GCB-4303-L2CD | 155M CSFP, FE/OC-3/STM-1, 1490nm-Tx DFB 1310nm-Rx PIN, 20km, SMF, Dual LC connectors |
| GCB-3403-L2TD | 155M CSFP, FE/OC-3/STM-1, 1310nm-Tx FP 1490nm-Rx PIN, 20km, SMF, Dual LC connectors, Industrial Grade |
| GCB-4303-L2TD | 155M CSFP, FE/OC-3/STM-1, 1490nm-Tx DFB 1310nm-Rx PIN, 20km, SMF, Dual LC connectors, Industrial Grade |
| GCB-3503-L2CD | 155M CSFP, FE/OC-3/STM-1, 1310nm-Tx DFB 1550nm-Rx PIN, 20km, SMF, Dual LC connectors |
| GCB-5303-L2CD | 155M CSFP, FE/OC-3/STM-1, 1550nm-Tx DFB 1310nm-Rx PIN, 20km, SMF, Dual LC connectors |
| GCB-3503-L2TD | 155M CSFP, FE/OC-3/STM-1
, 1310nm-Tx DFB 1550nm-Rx PIN, 20km, SMF, Dual LC connectors, Industrial Grade |
| GCB-5303-L2TD | 155M CSFP, FE/OC-3/STM-1, 1550nm-Tx DFB 1310nm-Rx PIN, 20km, SMF, Dual LC connectors, Industrial Grade |
| GCB-3403-L4CD | 155M CSFP, FE/OC-3/STM-1, 1310nm-Tx FP 1490nm-Rx PIN, 40km, SMF, Dual LC connectors |
| GCB-4303-L4CD | 155M CSFP, FE/OC-3/STM-1, 1490nm-Tx DFB 1310nm-Rx PIN, 40km, SMF, Dual LC connectors |
- Hot-pluggable SFP form factor
- Full-duplex transceiver module
- Dual-channel FP/DFB transmitters and PIN receivers
- Compliant with SFP MSA and Fast Ethernet standards
- Compatible with synchronous optical network (SONET OC-3 / SDH STM-1) standards
- Each channel supports a maximum data rate of 155Mbps
- Transmission distance of up to 20km-40km over a pair of single-mode fibers
- Dual LC connectors
- Built-in digital diagnostic functions
- Commercial operating temperature range from 0 to 70 degrees Celsius or industrial operating temperature range from -40 to +85 degrees Celsius
- Power supply voltage of 3.3V
- Compliant with RoHS environmental standards (lead-free)
