QSFP

    200G QSFP56

    The GIGALIGHT 200G QSFP56 pluggable optical transceiver modules support 200G Ethernet and InfiniBand HDR data rates. This portfolio includes SR4 100m, DR4 500m, FR4/PSM4 2km, LR4/PSM4 10km, XPSM4 15km, and ER4 40km etc.

    Get a Quote

    Description

    • Hot-pluggable QSFP56 transceiver modules
    • 4x 50G PAM4 electrical interface
    • 4x 50G PAM4 optical interface
    • Data rate up to 53.125Gbps per channel
    • Compliant with QSFP56 MSA, CMIS and IEEE 802.3
    • Low power dissipation
    • Commercial case operating temperature range
    • Single 3.3V power supply
    • Built-in digital diagnostic functionality
    • RoHS compliant (lead free)

    Ordering Information

    P/NDescriptionModulation WavelengthDistanceConnectorMax. Power Dissipation
    GQS-MPO201-SR4C200G QSFP56 SR44x50G PAM4 850nm100mMPO125W
    GQS-SPO201-DR4CZ200G QSFP56 DR4 4x50G PAM41310nm EML500mMPO125W
    GQS-SPO201-FR4C200G QSFP56 FR44x50G PAM4CWDM4 DML2kmDual LC 5.5W
    GQS-SPO201-FR4CZ200G QSFP56 FR44x50G PAM4CWDM4 EML 2kmDual LC7W
    GQS-SPO201-LR4C200G QSFP56 LR44x50G PAM4CWDM4 DML /
    LWDM4 DML /
    LWDM4 EML     		10kmDual LC7W
    GQS-SPO201-ER4C200G QSFP56 ER44x50G PAM4LWDM440kmDual LC7.5W
