40G QSFP+ ZR4 LWDM4 80km Optical Transceiver Modules

40G QSFP+ ZR4 EML LWDM4 80km Transceivers

GIGALIGHT's 40G QSFP+ ZR4 optical transceiver modules are designed to support 40G Ethernet and OTN OTU3, suitable for data center and telecom links up to 80km (with FEC, BER=10^-5) over single mode fiber. The 40G QSFP+ ZR4 modules operate at four LWDM (short for LAN-WDM) wavelengths of 1295.56nm, 1300.05nm, 1304.58nm and 1309.14nm.Get a Quote

Features

Applications

Datasheets

Hot-pluggable QSFP+ form factor full-duplex transceiver module
4-channel cooled LWDM EML TOSA and PIN ROSA with SOA
Data rate up to 11.18Gbps per channel
Compliant with QSFP+ MSA (SFF-8665) and 40G Ethernet
Compliant with OTN OTU3
Internal CDR circuits on both receiver and transmitter channels
Reach up to 80km over SMF with FEC
Duplex LC receptacle
6W maximum power dissipation
Case operating temperature range: C-Temp
Single 3.3V power supply
Built-in digital diagnostic functionality
RoHS compliant (lead free)

Part Number	Product Description
GQS-SPO401-ZR4C	40GE/OTU3 QSFP+ ZR4 EML LWDM4 80km Transceiver

40G Ethernet
OTN OTU3/OTU3e1/OTU3e2
Data Center Interconnection
Telecom Network
