40G QSFP+ AOC

GIGALIGHT's 40G QSFP+ AOC (Active Optical Cable) assemblies are designed to support 40G Ethernet and InfiniBand SDR/DDR/QDR, suitable for data center and HPC (High-Performance Computing) links up to 100m or 150m over multi-mode fiber.Get a Quote
Features
Applications
Datasheets
More
  • Hot-pluggable QSFP+ form factor full-duplex active optical cable assembly
  • 4-channele 850nm VCSEL array and PIN photo-detector array
  • Data rate up to 10.3125Gbps per channel
  • Compliant with QSFP+ MSA (SFF-8436) and IEEE 802.3ba 40GBASE-SR4
  • Compliant with InfiniBand SDR/DDR/QDR
  • MMF cable with customizable length up to 100m (OM3) or 150m (OM4)
  • 1.5W maximum power dissipation per 40G QSFP+ SR4 module
  • Case operating case temperature range: C-Temp or I-Temp
  • 3.3V power supply voltage
  • Built-in digital diagnostic functionality
  • RoHS compliant (lead free)
Part Number Product Description
GQS-MDO400-xxxC 40G QSFP+ AOC, 40G QSFP+ to 40G QSFP+, 40GE/QDR, 850nm, 1m-150m, C-Temp
GQS-MDO400-xxxT 40G QSFP+ AOC, 40G QSFP+ to 40G QSFP+, 40GE/QDR, 850nm, 1m-150m, T-Temp

Note:The "xxx" in the part number means the cable length, e.g., 001=1m, 002=2m, 010=10m, 100=100m, etc.

  • 40G Ethernet IEEE 802.3ba 40GBASE-SR4
  • InfiniBand 4x SDR/DDR/QDR
  • Data Center Intraconnection
  • High-Performance Computing
  •
  •
