100M-2.67G DWDM SFP Optical Transceiver Modules

100M-2.67G DWDM SFP

The Gigalight DWDM SFP optical transceiver modules are designed for Fast Ethernet, Gigabit Ethernet, 1G/2G Fibre Channel and SDH STM-1/8/16 links reach up to 40km-120km over Single-Mode Fiber (SMF).Get a Quote
Features
Applications
Datasheets
More

100M-2.67G Multirate DWDM SFP C17-C61 80km - GPD-xxMR-08CD

Part Number Product Description
GPD-17MR-08CD Multirate DWDM SFP, 100M-2.67G, C17 1563.86nm, 80km, SMF, Dual LC
GPD-18MR-08CD Multirate DWDM SFP, 100M-2.67G, C18 1563.05nm, 80km, SMF, Dual LC
... ...
GPD-61MR-08CD Multirate DWDM SFP, 100M-2.67G, C61 1528.77nm, 80km, SMF, Dual LC
  • Wavelength selectable to C-band C17-C61 ITU-T grid wavelengths
  • Suitable for use in 100GHz channel spacing DWDM systems
  • DWDM SFP MSA Compliant
  • Up to 2.67Gb/s data rate
  • Cold Start up Wavelength Compliance
  • Low Power Dissipation < 1.3W Maximum
  • -5°C to 70°C Operating Case Temperature
  • Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power, Laser temperature and TEC current
  • Extended link budget with APD receiver technology
  • OC48/STM-16 Long Reach 80km, OC-3/OC-24 120km Versions
  • 3.3V power supply voltage
  • RoHS compliant and lead free

2.67G DWDM SFP C17-C61 80km - GPD-xx48-08CD

Part Number Product Description
GPD-1748-08CD 2.67G DWDM SFP, C17 1563.86nm, 80km, SMF, Dual LC
GPD-1848-08CD 2.67G DWDM SFP, C18 1563.05nm, 80km, SMF, Dual LC
... ...
GPD-6148-08CD 2.67G DWDM SFP, C61 1528.77nm, 80km, SMF, Dual LC
  • Wavelength selectable to C-band C17-C61 ITU-T grid wavelengths
  • Suitable for use in 100GHz channel spacing DWDM systems
  • DWDM SFP MSA Compliant
  • Up to 2.67Gb/s data rate
  • OC48 Long Reach 80km
  • Cold Start up Wavelength Compliance
  • Low Power Dissipation < 1.3W Maximum
  • -5°C to 70°C Operating Case Temperature
  • Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power, Laser temperature and TEC current
  • Extended link budget with APD receiver technology
  • OC48/STM-16 Long Reach 80km, OC-3/OC-24 120km Versions
  • 3.3V power supply voltage
  • RoHS compliant and lead free

1G DWDM SFP C17-C61 80km - GPD-xx24-08CD

Part Number Product Description
GPD-1724-08CD 1G DWDM SFP, C17 1563.86nm, 80km, SMF, Dual LC
GPD-1824-08CD 1G DWDM SFP, C18 1563.05nm, 80km, SMF, Dual LC
... ...
GPD-6124-08CD 1G DWDM SFP, C61 1528.77nm, 80km, SMF, Dual LC
  • Wavelength selectable to C-band C17-C61 ITU-T grid wavelengths
  • Suitable for use in 100GHz channel spacing DWDM systems
  • DWDM SFP MSA Compliant
  • Dual data-rate of 1.25Gbps/1.063Gbps operation
  • OC-24 Long Reach 80km
  • Cold Start up Wavelength Compliance
  • Low Power Dissipation < 1.3W Maximum
  • -5°C to 70°C Operating Case Temperature
  • Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power, Laser temperature and TEC current
  • Extended link budget with APD receiver technology
  • OC48/STM-16 Long Reach 80km, OC-3/OC-24 120km Versions
  • 3.3V power supply voltage
  • RoHS compliant and lead free

1G DWDM SFP C17-C61 120km - GPD-xx24-12CD

Part Number Product Description
GPD-1724-12CD 1G DWDM SFP, C17 1563.86nm, 120km, SMF, Dual LC
GPD-1824-12CD 1G DWDM SFP, C18 1563.05nm, 120km, SMF, Dual LC
... ...
GPD-6124-12CD 1G DWDM SFP, C61 1528.77nm, 120km, SMF, Dual LC
  • Wavelength selectable to C-band C17-C61 ITU-T grid wavelengths
  • Suitable for use in 100GHz channel spacing DWDM systems
  • DWDM SFP MSA Compliant
  • Dual data-rate of 1.25Gbps/1.063Gbps operation
  • OC-24 120km range
  • Cold Start up Wavelength Compliance
  • Low Power Dissipation < 1.3W Maximum
  • -5°C to 70°C Operating Case Temperature
  • Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power, Laser temperature and TEC current
  • Extended link budget with APD receiver technology
  • 3.3V power supply voltage
  • RoHS compliant and lead free
  • Fast Ethernet
  • Gigabit Ethernet
  • 1G/2G Fibre Channel
  • SONET OC-3/24/48
  • SDH STM-1/8/16
  •
  •
  •
  •
  •
